Multicore Copper Flexible Fire Alarm Cable , Smoke Alarm Cable 6C UTP 0.22mm²

Brand Name : OEM Produce

Model Number : 6C 0.22MM2 Alarm Cable

Certification : CPR. CE. ROHS.

Place of Origin : Hangzhou, China

MOQ : 10km

Price : FOB Shanghai Price: 30USD/200m

Payment Terms : TT. LC

Supply Ability : 5000km/ Month

Delivery Time : 20days after deposit

Packaging Details : 100M. 200M. 300M. 1000FT. 500M. Reel

Type Name : Security And Alarm Cable

Jacket Color : White PVC

Shield : Unshield

Inner Conductor : CCA/ BC/ TC

Condoctor Type : Stranded

Application : Alarm system, Security system, Lighting

Packing : 100M reel or Customized

Contact Now

Scurity Alarm Cable Flexible 6C UTP 0.22mm² Soft Multicore Copper Wire

C: Structure of unshielded 0.22mm² soft alarm cable
Serial NO. Section Specification Overall Diameter(mm)
C-01 2*0.22mm² 2*7/0.20 3
C-02 4*0.22mm² 4*7/0.20 3.5
C-03 6*0.22mm² 6*7/0.20 4.1
C-04 8*0.22mm² 8*7/0.20 4.5
C-05 10*0.22mm² 10*7/0.20 5.2
C-06 12*0.22mm² 12*7/0.20 5.4
C-07 14*0.22mm² 14*7/0.20 5.8
C-08 20*0.22mm² 20*7/0.20 6.8
C-09 30*0.22mm² 30*7/0.20 8.5
C-10 40*0.22mm² 40*7/0.20 10
C-11 2*0.5+2*0.22mm² 2*16/0.20+2*7/0.20 3.9
C-12 2*0.5+4*0.22mm² 2*16/0.20+4*7/0.20 4.5
C-13 2*0.5+6*0.22mm² 2*16/0.20+6*7/0.20 4.9
C-14 2*0.5+8*0.22mm² 2*16/0.20+8*7/0.20 5.7
C-15 2*0.5+10*0.22mm² 2*16/0.20+10*7/0.20 6
C-16 2*0.5+12*0.22mm² 2*16/0.20+12*7/0.20 6.3
C-17 2*0.75+2*0.22mm² 2*24/0.20+2*7/0.20 4.2
C-18 2*0.75+4*0.22mm² 2*24/0.20+4*7/0.20 4.9
C-19 2*0.75+6*0.22mm² 2*24/0.20+6*7/0.20 5.3
C-20 2*0.75+8*0.22mm² 2*24/0.20+8*7/0.20 6.2

Electrical Characteristics

Temperature Rating -20℃ to 60℃
Operating Voltage 24/12V
DC Resistance per Conductor@ 20℃ 6.32 Ohms/1M’Nom

Multicore Copper Flexible Fire Alarm Cable , Smoke Alarm Cable 6C UTP 0.22mm²Multicore Copper Flexible Fire Alarm Cable , Smoke Alarm Cable 6C UTP 0.22mm²

If you have technical support from an engineer, please let us know the type of cables you need, the inner conductor, the braiding coverage, the jakcet material and color, the packing length and design, and the application. We will help you choose the most suitable cable.

If you are not sure about certain specifications of the electric cables, please let us know your inquiry and we are very happy to give you professional technical advice and support services. Our company offer specific cables and wires consulting, design, OEM and manufacturing based on the customer's requirements and application scenarios to help customers create more business opportunities.
